Ping 360 Scanning Sonar

GENERAL SENSOR INFORMATION

Device PID (L22) -

SCOOP PID SCOOP22

Sensor name Ping 360 Scanning Sonar

Instrument Type (L05) MPIS

Version -

Parameters

Technology Readiness Level (TRL) 9 - Actual system proven in operational environment (Successful mission deployment)

Assembly Type Purchase of complete unit

Price category $2,001 - $10,000

Sensor Lifetime Months Indefinite

Power Supply Type 11–25 V DC

Battery Lifetime Days -

Accuracy Performance 0.08% of range, 0.9 degree

Length 89 cm

Width 83 cm

Depth 77 cm

Weight 0.51 kg

Measurement Range 0.75 to 50m

Service providers can be developers, manufacturers, or resellers.

Name Blue Robotics

Description -

Contact Tony White

Data Transmission Range USB / Ethernet

Data Transmission Frequency real-time

Data Format Ping protocol

Keywords Distance to objects 360 horizontal plane

Documentation -

Documents -

Last Update 2025-05-19 15:22:24
