Ping Sonar Altimeter and Echosounder

1/0

Altitude sensor, range sensor, coarse bathymetric survey

GENERAL SENSOR INFORMATION

Device PID (L22) -

SCOOP PID SCOOP24

Sensor name Ping Sonar Altimeter and Echosounder

Instrument Type (L05) MPIS

Version -

Parameters

Technology Readiness Level (TRL) 9 - Actual system proven in operational environment (Successful mission deployment)

Assembly Type Purchase of complete unit

Price category $101 - $500

Sensor Lifetime Months Indefinite

Power Supply Type 4.5–5.5 V DC

Battery Lifetime Days -

Accuracy Performance 0.5% of total range accuracy

Length 4.1 cm

Width 71.1 cm

Depth 4.7 cm

Weight 0.187 kg

Measurement Range 0.3 to 100m distance

Service providers can be developers, manufacturers, or resellers.

Name Blue Robotics

Description -

Contact Tony White

Data Transmission Range Serial USB

Data Transmission Frequency real time

Data Format Ping protocol

Keywords Distance

Documentation -

Video -

Documents -
